Solenoid Valve for Gas, Class A, 500 mbar, IP65, EN 161

The HONEYWELL KROMSCHRODER VAS1-/20R/LWSL is a Class A solenoid valve intended for use in applications requiring automatic shut-off of gas and air. This unit compliant with EN 161 standards, the valve is closed when not energized, and supports a maximum operating pressure of 500 mbar. It features an integrated pilot lamp for status indication and adjustable flow setting, offering visual feedback and control over media flow.

Key features include:

• Size range: 1 to 9; nominal diameter (DN) from 10 to 125
• Connection options: threaded or flanged
• Operation modes: quick opening/quick closing or slow opening/quick closing
• Mains voltage compatibility: 24 V DC, 120 V AC, or 230 V AC
• Electrical connection via terminal block
• Protection rating: IP65
• Certifications: EU certified, FM approved, CSA approved; rated for use in systems classified up to SIL 3 and PL e Additional versions are available with position indicators, bypass/pilot gas valves, or fitted pressure switches.
