Solenoid Valve for Gas, Class A, 500 mbar, IP65 Rated

The HONEYWELL KROMSCHRODER VAS1-0/10R/NW is a Class A solenoid valve intended for use in applications requiring automatic shut-off of gas and air. It operates per EN 161 standards; valve is normally closed when de-energized. This model supports a maximum operating pressure of 500 mbar and includes features such as a pilot lamp and flow adjustment. The unit is rated IP65 for ingress protection and holds EU certification, along with FM and CSA approvals. It is also certified for use in systems up to SIL 3 and PL e.

Key features include:

• Size range: 1 to 9; DN (nominal diameter): 10 to 125
• Connection options: threaded or flanged
• Operation types: quick opening/quick closing or slow opening/quick closing
• Mains voltage compatibility: 24 V DC, 120 V AC, or 230 V AC
• Electrical connection via terminal block
• Available versions include models with position indicators, visual indicators, fitted bypass/pilot gas valves, or fitted pressure switches
