Solenoid Valve for Gas, Class A, 500 mbar, IP65 Rated

The HONEYWELL KROMSCHRODER VAS1T15/-N/NKGR is a Class A solenoid valve intended for use in applications requiring the control of gas and air flow. This unit is rated to meet EN 161 standards, and it is normally closed when not energized. It features a pilot lamp and flow adjustment, supports a maximum operating pressure of 500 mbar, and has an ingress protection rating of IP65. The valve has been assessed according to SIL 3 and PL e requirements, with FM and CSA certifications.

Key features include:

• Size range: 1 to 9; DN (nominal diameter): 10 to 125
• Connection options: threaded or flanged
• Opening/closing types: quick opening/quick closing or slow opening/quick closing
• Mains voltage compatibility: 24 V DC, 120 V AC, or 230 V AC
• Electrical connection via terminal
• Available versions include models with position indicator, visual indicator, fitted bypass or pilot gas valve, and fitted pressure switches DG../VC
