Solenoid Valve for Gas, Class A, 500 mbar, IP65 Rated

The HONEYWELL KROMSCHRODER Solenoid Valve is a Class A solenoid valve intended for use in gas and air systems with automatic shut-off functionality per manufacturer specifications. It is configured as a normally closed valve; the default state is closed when not energized, and features rated for operation at pressures up to 500 mbar. The unit contains a pilot lamp and allows manual flow adjustment within specified parameters, is rated IP65 for ingress protection, and holds EU, FM, and CSA certifications; suitable for installation in systems requiring compliance up to SIL 3 or PL e standards.

Key features include:

• Size range: 1 to 9; DN (nominal diameter): 10 to 125
• Connection options: threaded or flanged
• Operation types: quick opening/quick closing or slow opening/quick closing
• Mains voltage compatibility: 24 V DC, 120 V AC, or 230 V AC
• Electrical connection via terminal block
• Available versions include models with position indicator, visual indicator, fitted bypass/pilot gas valve, or integrated pressure switches
