Solenoid Valve for Gas, Class A, 500 mbar, IP65 Rated

The HONEYWELL KROMSCHRODER VCS665F05NNWR3E/P3PP/PPPP is a Class A solenoid valve intended for use in the automatic shut-off of gas and air lines. This unit operates in a normally closed position when de-energized and supports maximum operating pressure up to 500 mbar. It features an integrated pilot lamp, flow adjustment capability, and offers protection rated at IP65. The valve holds EU certification as well as FM and CSA approvals, with rated for use in systems requiring up to SIL 3 and PL e.

Key features include:

• Size range: 1 to 9; nominal diameter (DN): 10 to 125
• Connection options: threaded or flanged
• Opening/closing types: quick opening & closing or slow opening & quick closing
• Mains voltage compatibility: 24 V DC, 120 V AC, or 230 V AC
• Electrical connection via terminal block
• Available versions include models with position indicator, visual indicator, fitted bypass/pilot gas valve, or fitted pressure switches
