Solenoid Valve for Gas, Class A, 500 mbar, IP65, SIL 3

The HONEYWELL KROMSCHRODER VAS665F05NWSRE/PP/PP is a Class A solenoid valve intended for use in applications requiring the automatic shut-off of gas and air. It operates in accordance with EN 161 standards, remains closed when not energized, and supports a maximum operating pressure of 500 mbar. The unit features a pilot lamp and adjustable flow settings, is rated IP65 for ingress protection, and holds EU certification as well as FM and CSA approvals. This model is certified according to SIL 3 and PL e requirements.

Key features include:

• Size range: 1 to 9; DN (nominal diameter): 10 to 125
• Connection options: threaded or flanged
• Opening/closing action: available with either rapid or gradual opening/closing mechanisms
• Mains voltage compatibility: compatible with mains voltages of 24 V DC, 120 V AC, or 230 V AC
• Electrical connection via terminal block
• Available variants may include position indicators, visual indicators, integrated bypass/pilot gas valves, or integrated pressure switches
