Solenoid Valve for Gas, Class A, EN 161, IP65, 500 mbar
Mfr # KS88206838
Zoro # G715422187
Specifications
Product Information
Description
The HONEYWELL KROMSCHRODER VAS7T80A05LKGLB/PP/PP is a Class A solenoid valve conforming to EN 161 standards. This valve is intended for use in applications requiring automatic shut-off of gas and air, conforming to EN 161 standards. The valve is configured to be in a closed position when not energized and supports a maximum operating pressure of 500 mbar. Equipped with pilot lamp and adjustable flow settings, it features an IP65 rating for ingress protection. The unit holds EU certification as well as FM and CSA approvals, and it is certified for use in systems up to SIL 3 and PL e.
Key features include:
- Size range: 1 to 9; DN (nominal diameter): 10 to 125
- Connection options: threaded or flanged
- Operation types: quick opening/quick closing or slow opening/quick closing
- Mains voltage compatibility: 24 V DC, 120 V AC, or 230 V AC
- Electrical connection via terminal block
- Available versions include models with position indicator, visual indicator, fitted bypass or pilot gas valve, and fitted pressure switches DG../VC
