Solenoid Valve for Gas, Class A, EN 161, IP65, 500 mbar Max

The HONEYWELL KROMSCHRODER VAS225R/NW is a Class A solenoid valve conforming to EN 161 standards. This valve remains closed when de-energized and features a pilot lamp and flow adjustment. It is suitable for use with maximum operating pressures up to 500 mbar, with an ingress protection rating of IP65. The product holds EU certification as well as FM and CSA approvals, and it holds certification meeting requirements up to SIL 3 and PL e.

Key features include:

• Size range: 1 to 9
• Nominal diameter (DN): 10 to 125
• Connection types: threaded or flanged
• Operation options: quick opening/quick closing or slow opening/quick closing
• Mains voltage compatibility: 24 V DC, 120 V AC, or 230 V AC
• Electrical connection via terminal block
• Available versions with position indicator, visual indicator, fitted bypass/pilot gas valve, or fitted pressure switches
