Solenoid Valve for Gas, Class A, EN 161, IP65, SIL 3

The HONEYWELL KROMSCHRODER VAS240F/NQSL is a Class A solenoid valve conforming to EN 161 standards. The valve remains closed when de-energized and features a pilot lamp and flow adjustment. It is suitable for use with maximum operating pressures up to 500 mbar, rated to IP65 ingress protection standard, and holds EU certification as well as FM and CSA approvals. This model is certified for systems up to SIL 3 and PL e.

Key features include:

• Size range: 1 to 9; nominal diameter (DN): 10 to 125
• Connection options: threaded or flanged
• Opening/closing types: quick opening/quick closing or slow opening/quick closing
• Mains voltage compatibility: 24 V DC, 120 V AC, or 230 V AC
• Electrical connection via terminal block
• Available versions include models with position indicator, visual indicator, fitted bypass or pilot gas valve, and fitted pressure switches DG../VC
