Solenoid Valve for Gas, DN 80 mm, ISO Flange, 500 mbar, IP65 Rated

The HONEYWELL KROMSCHRODER VAS780F05L is a solenoid valve intended for use in the control of gas and air line flow. Classified as a Class A valve to EN 161 standards, it is configured to be closed in a de-energized state and features an ISO flange connection with an 80 mm nominal diameter. The unit operates at a maximum pressure of 500 mbar and includes both pilot lamp indication and flow adjustment capabilities.

Key features include:

• Valve size: SZ 7 (DN 80 mm)
• Connection type: ISO flange
• Provides selectable actuation speeds as specified by manufacturer
• Maximum operating pressure: 500 mbar
• Electrical options: Available in 24 V DC, 120 V AC, or 230 V AC mains voltage
• Enclosure rated IP65 according to IEC 60529 standard
• Certifications: EU certified, FM and CSA approved; certified according to SIL 3 (IEC 61508) and PL e (EN ISO 13849-1) standards
