Solenoid Valve for Gas – Fast Opening, Class A, 500 mbar, IP65 Rated

The HONEYWELL KROMSCHRODER VLV,SOLND,SZ 3,RP,VAS3 /NWGL,FAST OPNG is a solenoid valve intended for use in applications requiring the control of gas and air flow. Classified as a Class A valve to EN 161 standards, it remains closed when de-energized and rated for operation at pressures up to 500 mbar. The unit features an equipped with a rapid actuation mechanism and includes both pilot lamp indication and flow adjustment capabilities.

Key features include:

• Size range: 1 to 9; DN (nominal diameter): 10 to 125
• Connection options: threaded or flanged
• Opening/closing types: available with rapid or gradual closing options
• Mains voltage compatibility: Compatible with mains voltages of 24 V DC, 120 V AC, or 230 V AC
• Electrical connection via terminal block
• Rated IP65
• Certifications: Certified according to EU standards; FM and CSA approvals; meets requirements for use in systems classified as SIL 3 and PL e
• Additional versions available with position indicators, bypass/pilot gas valves, or fitted pressure switches
