Solenoid Valve for Gas, NC, 500 mbar, IP65, EN 161

The HONEYWELL KROMSCHRODER VAS240R/NW is a Class A solenoid valve intended for use in applications requiring automatic shut-off of gas and air, conforming to EN 161 standards. The valve is normally closed (NC) type; closure occurs when not energized and features a pilot lamp indicator and adjustable flow settings. It is rated for operation up to 500 mbar and has an ingress protection rating of IP65. The unit is EU certified, FM and CSA approved, and certified according to SIL 3 and PL e standards.

Key features include:

• Size range: 1 to 9; DN (nominal diameter): 10 to 125
• Connection options: threaded or flanged
• Operation types: quick opening/quick closing or slow opening/quick closing
• Mains voltage compatibility: 24 V DC, 120 V AC, or 230 V AC
• Electrical connection via terminal block
• Available versions with position indicator, visual indicator, fitted bypass/pilot gas valve, or fitted pressure switches
