Solenoid Valve for Gas, VAS Series, 500 mbar, IP65, FM/CSA Approved

The HONEYWELL KROMSCHRODER VAS1-/25R/LQSR is a Class A solenoid valve intended for use in applications requiring the control of gas and air flow. It is configured to be closed in a de-energized state. The unit is rated for operation at pressures up to 500 mbar, features flow adjustment, and includes a pilot lamp for status indication. It is certified to EU standards as well as FM and CSA approvals, with may be used in systems with requirements up to SIL 3 and PL e, subject to proper application.

Key features include:

• Size range: 1 to 9; nominal diameter (DN): 10 to 125
• Connection options: threaded or flanged
• Opening/closing types: quick opening/quick closing or slow opening/quick closing
• Mains voltage compatibility: 24 V DC, 120 V AC, or 230 V AC
• Electrical connection via terminal block
• Protection rating: IP65
• Available versions include models with position indicators, visual indicators, fitted bypass/pilot gas valves, or integrated pressure switches
