Solenoid Valve for Gas, VAS9125F0, DN 125 mm, ISO Flange, 500 mbar
Mfr # KS88204553
Zoro # G315296409
Specifications
Product Information
Details
Description
The HONEYWELL KROMSCHRODER VAS9125F0 is a solenoid valve intended for use in applications requiring automatic shut-off of gas and air lines. Classified as a Class A valve to EN 161 standards, it operates in the closed position when de-energized and supports maximum operating pressures up to 500 mbar. The unit features an ISO flange connection with a nominal diameter of 125 mm (size 9), includes flow adjustment capabilities, and features a pilot lamp that provides status indication. It holds EU certification as well as FM and CSA approvals, and is certified for use in systems rated up to SIL 3 and PL e.
Key features:
- Valve size: 9; DN: 125 mm
- Connection type: ISO flange
- Operating pressure: Up to 500 mbar
- Electrical options: Available in mains voltages of 24 V DC, 120 V AC, or 230 V AC; terminal electrical connection
- Opening/closing action: Quick opening/quick closing or slow opening/quick closing variants available
- Additional components: Pilot lamp included; flow adjustment feature present ([see above])
- Protection rating: IP65
