Solenoid Valve for Gas, VCS780F05NNKGRB, 500 mbar, IP65, Class A

The HONEYWELL KROMSCHRODER VCS780F05NNKGRB/PPPP/PPPP is a Class A solenoid valve intended for use in applications requiring the control of gas and air flow. It operates per EN 161 standards; the valve is closed when not energized. This model is rated for a maximum operating pressure (pu max.) of 500 mbar and includes features such as a pilot lamp and adjustable flow. The unit is rated IP65 for ingress protection and holds EU certification, along with FM and CSA approvals. It is certified for use in systems up to SIL 3 and PL e.

Key features include:

• Size range: 1 to 9
• Nominal diameter (DN): 10 to 125
• Connection options: threaded or flanged
• Operation modes: quick opening/closing or slow opening/quick closing
• Mains voltage compatibility: 24 V DC, 120 V AC, or 230 V AC
• Electrical connection via terminal block
• Available versions include models with position indicator, visual indicator, fitted bypass or pilot gas valve, and fitted pressure switches DG../VC
