Solenoid Valve for Gas, VG Series, Class A, 100 mbar Max Pressure

The HONEYWELL KROMSCHRODER VLV, SOLND, VG 10R01T5 is a solenoid valve intended for use with compatible gas and air systems as specified by the manufacturer. Classified under EN 161 standards as a Class A valve, this unit is equipped with an automatic shut-off mechanism and is in a closed position when not energized, per design specifications. It is EU certified and rated for operation at pressures up to 100 mbar maximum with supply voltages of either 220V or 24V, as specified.

Key features include:

• Nominal diameter (DN) range: 6 to 65
• Connection types: double-cone olive, thread, or flange
• Maximum operating pressure (pu): up to 100 mbar
• Opening/closing characteristics: quick opening and closing or slow opening with quick closing
• Electrical connection options: terminals or standard plug with socket
• Available versions include low-noise valves, valves with flow adjustment, compatibility for biologically produced methane, and Viton valve disc seal
