Solenoid Valve for Gas/Air, 500 mbar, IP65, Class A

The HONEYWELL KROMSCHRODER VAS1T20/-N/NQSR is a Class A solenoid valve intended for use in applications requiring automatic shut-off of gas and air. The valve is configured to be closed when not energized and operates at a maximum pressure of 500 mbar. It includes a pilot lamp, flow adjustment capability, and has an IP65 ingress protection rating. The unit is EU certified, FM and CSA approved, and compatible with systems rated up to SIL 3 and PL e.

Key features include:

• Size range: 1 to 9; DN (nominal diameter): 10 to 125
• Connection options: threaded or flanged
• Opening/closing types: quick opening/quick closing or slow opening/quick closing
• Mains voltage options: 24 V DC, 120 V AC, or 230 V AC
• Electrical connection via terminal block
• Available versions with position indicator, visual indicator, fitted bypass/pilot gas valve, or fitted pressure switches DG../VC
