Solenoid Valve for Gas/Air, 500 mbar, IP65, Class A

The HONEYWELL KROMSCHRODER VAS1T25/-N/NQSL is a Class A solenoid valve intended for use in applications requiring automatic shut-off of gas and air. It operates according to EN 161 standards, is closed when not energized, and supports a maximum operating pressure of 500 mbar. This model features a pilot lamp and adjustable flow mechanism, with an IP65 ingress protection rating. The valve holds EU, FM, and CSA certifications; suitable for installation in systems requiring up to SIL 3 or PL e certification.

Key features include:

• Size range: 1 to 9; DN (nominal diameter): 10 to 125
• Connection options: threaded or flanged
• Operation types: quick opening/quick closing or slow opening/quick closing
• Mains voltage compatibility: 24 V DC, 120 V AC, or 230 V AC
• Electrical connection via terminal block
• Available versions include models with position indicators, visual indicators, fitted bypass/pilot gas valves, or fitted pressure switches
