Solenoid Valve for Gas/Air, 500 mbar, IP65, Class A
Mfr # KS88018862
Zoro # G715411358
Specifications
Product Information
Description
The HONEYWELL KROMSCHRODER VAS1T15/-N/NWGR is a Class A solenoid valve intended for use in applications requiring the automatic shut-off of gas and air. It compliant with EN 161 standards, the valve is in a closed position when not energized. This valve is rated for a maximum operating pressure of 500 mbar and includes pilot lamp indication and flow adjustment functionality. The unit is rated IP65 for ingress protection and holds EU certification as well as FM and CSA approvals. It holds certification meeting requirements up to SIL 3 and PL e.
Key features include:
- Size range: 1 to 9; nominal diameter (DN): 10 to 125
- Connection options: threaded or flanged
- Operation types: quick opening/quick closing or slow opening/quick closing
- Mains voltage compatibility: 24 V DC, 120 V AC, or 230 V AC
- Electrical connection via terminal block
- Available with position indicator, visual indicator, fitted bypass/pilot gas valve, or fitted pressure switches DG../VC
