Solenoid Valve for Gas/Air, 500 mbar, IP65, Class A

The HONEYWELL KROMSCHRODER VAS3T-/40N/LQSL is a Class A solenoid valve intended for use in systems requiring automatic shut-off of gas and air. When de-energized, the valve is in a closed position and operates at a maximum pressure of 500 mbar. It is equipped with a pilot lamp, adjustable flow settings, and rated IP65 for ingress protection. The unit holds certifications including EU standards compliance as well as FM and CSA approvals, and it is suitable for installation in systems with specifications up to SIL 3 and PL e.

Key features include:

• Size range: 1 to 9
• Nominal diameter (DN): 10 to 125
• Connection options: threaded or flanged
• Operation types: quick opening/quick closing or slow opening/quick closing
• Mains voltage options: 24 V DC, 120 V AC, or 230 V AC
• Electrical connection via terminal block
• Available versions with position indicator (visual), fitted bypass/pilot gas valve, or integrated pressure switches
