Solenoid Valve for Gas/Air, 500 mbar, IP65, Class A

The HONEYWELL KROMSCHRODER VAS120/-R/NW is a Class A solenoid valve intended for use in applications requiring automatic shut-off of gas and air. It remains closed when de-energized and includes a pilot lamp and adjustable flow mechanism. It is rated for operation at pressures up to 500 mbar, with an IP65 rating for ingress protection. The unit holds EU certification as well as FM and CSA approvals, and it is suitable for installation in systems with requirements up to SIL 3 and PL e.

Key features include:

• Size range: 1 to 9; DN (nominal diameter): 10 to 125
• Connection options: threaded or flanged
• Operation types: quick opening/quick closing or slow opening/quick closing
• Compatible with mains voltages of 24 V DC, 120 V AC, or 230 V AC
• Electrical connection provided by terminal block
• Available versions include models equipped with position indicators, visual indicators, bypass/pilot gas valves, or pressure switches
