Solenoid Valve for Gas/Air, 500 mbar, IP65, Class A

The HONEYWELL KROMSCHRODER VCS665F05NLWR3E/P3PP/PMEP is a Class A solenoid valve intended for use in applications requiring automatic shut-off of gas and air. It operates in accordance with EN 161 standards and remains closed when de-energized. This valve is rated for a maximum operating pressure of 500 mbar, features a pilot lamp and flow adjustment, and has an ingress protection rating of IP65. The unit is certified to applicable EU, FM, and CSA standards, with suitability for systems up to SIL 3 and PL e.

Key features include:

• Size range: 1 to 9; DN (nominal diameter): 10 to 125
• Connection options: threaded or flanged
• Operation types: quick opening/quick closing or slow opening/quick closing
• Compatible with mains voltages of 24 V DC, 120 V AC, or 230 V AC
• Electrical connection via terminal block
• Available in versions equipped with position indicator, visual indicator, bypass/pilot gas valve option, or fitted pressure switches DG../VC
