Solenoid Valve for Gas/Air, 500 mbar, IP65, EN 161 Class A

The HONEYWELL KROMSCHRODER VAS1T-/25N/NW is a Class A solenoid valve intended for use in applications requiring automatic shut-off of gas and air. It compliant with EN 161 standards, the valve is closed when not energized. This model is rated for a maximum operating pressure of 500 mbar and equipped with pilot lamp and flow adjustment. The unit is rated IP65 for ingress protection and holds EU certification, as well as FM and CSA approvals. It holds certification indicating suitability for systems up to SIL 3 and PL e.

Key features include:

• Size range: 1 to 9; nominal diameter (DN): 10 to 125
• Connection options: threaded or flanged
• Operation types: quick opening/quick closing or slow opening/quick closing
• Mains voltage compatibility: 24 V DC, 120 V AC, or 230 V AC
• Electrical connection via terminal block
• Available versions with position indicator, visual indicator, fitted bypass/pilot gas valve, or fitted pressure switches
