Solenoid Valve for Gas/Air, 500 mbar, IP65, EN 161, VAS-VCS Series
Mfr # KS88203189
Zoro # G515424336
Specifications
Product Information
Description
The HONEYWELL KROMSCHRODER VAS780F05LWSR3B/PP/PP is a Class A solenoid valve intended for use in applications requiring the automatic shut-off of gas and air. This valve operates in accordance with EN 161 standards, remaining closed when de-energized. It supports a maximum operating pressure of 500 mbar and features both pilot lamp indication and flow adjustment capabilities. The unit carries IP65 ingress protection and holds EU certification as well as FM and CSA approvals, making it suitable for use in systems rated up to SIL 3 and PL e.
Key features include:
- Size range: 1 to 9
- Nominal diameter (DN): 10 to 125
- Connection types: threaded or flanged
- Operation modes: quick opening/quick closing or slow opening/quick closing
- Mains voltage options: 24 V DC, 120 V AC, or 230 V AC
- Electrical connection via terminal block
- Available versions with position indicator, visual indicator, fitted bypass/pilot gas valve, or integrated pressure switches
