Solenoid Valve for Gas/Air, 500 mbar, IP65, VCS7T80A05NNQGLB

The HONEYWELL KROMSCHRODER VCS7T80A05NNQGLB/PPPP/MMPM is a Class A solenoid valve intended for use as an automatic shut-off valve for gas and air applications per EN 161 standards. The valve is configured to be closed in the de-energized state and rated for a maximum operating pressure of 500 mbar. It features an integrated pilot lamp, flow adjustment capability, and is rated IP65 for ingress protection. The unit holds EU certification as well as FM and CSA approvals, and it is certified for use in systems up to SIL 3 and PL e.

Key features include:

• Size range: 1 to 9; DN (nominal diameter): 10 to 125
• Connection options: threaded or flanged
• Opening/closing types: quick opening & closing or slow opening & quick closing
• Compatible with mains voltages of either 24 V DC, 120 V AC, or 230 V AC
• Electrical connection via terminal block
• Available versions with position indicator, visual indicator, fitted bypass/pilot gas valve, or fitted pressure switches DG../VC
