Solenoid Valve for Gas/Air, Auto Shut-Off, 500 mbar, IP65, VAS Series

The HONEYWELL KROMSCHRODER VAS1-/15R/NWGL is a Class A solenoid valve intended for use in automatic shut-off applications for gas and air, meeting EN 161 standards. The valve is configured to be in a closed position when de-energized and features a pilot lamp and flow adjustment. It is suitable for use with maximum operating pressures up to 500 mbar and carries EU certification as well as FM and CSA approvals. The unit is rated IP65 for ingress protection and certified for systems up to SIL 3 and PL e.

Key features include:

• Size range: 1 to 9; DN (nominal diameter): 10 to 125
• Connection options: threaded or flanged
• Operation types: quick opening/quick closing or slow opening/quick closing
• Mains voltage compatibility: 24 V DC, 120 V AC, or 230 V AC
• Electrical connection via terminal block
• Available versions with position indicator, visual indicator, fitted bypass/pilot gas valve, or pressure switches
