Solenoid Valve for Gas/Air, Class A, 500 mbar, IP65, EN 161

The HONEYWELL KROMSCHRODER VAS2T-/40N/NQGL is a Class A solenoid valve intended for use in applications requiring automatic shut-off of gas and air. This valve conforms to EN 161 standards, remains closed when not energized, and supports a maximum operating pressure of 500 mbar. It features include pilot lamp and flow adjustment. The unit is rated IP65 for ingress protection and holds EU certification, along with FM and CSA approvals. It is certified according to SIL 3 and PL e requirements.

Key features include:

• Size range: 1 to 9; nominal diameter (DN): 10 to 125
• Connection options: threaded or flanged
• Operation types: quick opening/quick closing or slow opening/quick closing
• Mains voltage compatibility: 24 V DC, 120 V AC, or 230 V AC
• Electrical connection via terminal block
• Available versions include models with position indicator, visual indicator, fitted bypass/pilot gas valve, or fitted pressure switches DG../VC
