Solenoid Valve for Gas/Air, Class A, 500 mbar, IP65

The HONEYWELL KROMSCHRODER VAS115/-R/NQSL is a Class A solenoid valve intended for use in applications requiring automatic shut-off of gas and air, conforming to EN 161 standards. This valve remains closed when de-energized and features a pilot lamp and flow adjustment. It operates at a maximum pressure of 500 mbar and has an ingress protection rating of IP65. The unit holds certifications indicating compliance with SIL 3 and PL e standards, with approvals from EU, FM, and CSA.

Key features include:

• Size range: 1 to 9; DN (nominal diameter): 10 to 125
• Connection options: threaded or flanged
• Operation types: quick opening/quick closing or slow opening/quick closing
• Mains voltage compatibility: 24 V DC, 120 V AC, or 230 V AC
• Electrical connection via terminal
• Available versions include models with position indicator/visual indicator, fitted bypass or pilot gas valve, and fitted pressure switches DG../VC
