Solenoid Valve for Gas/Air, Class A, 500 mbar, IP65

The HONEYWELL KROMSCHRODER VAS1T25/-N/NQ is a Class A solenoid valve intended for use in applications requiring the shut-off of gas and air. It conforms to EN 161 standards, remains closed when not energized, and is rated for operation at pressures up to 500 mbar. The unit includes a pilot lamp and adjustable flow setting, with an IP65 rating for ingress protection. This model holds EU certification as well as FM and CSA approvals, and it is certified for systems rated up to SIL 3 and PL e.

Key features include:

• Valve sizes from 1 to 9; DN (nominal diameter) range: 10 to 125
• Connection options: threaded or flanged
• Opening/closing types: quick opening/quick closing or slow opening/quick closing
• Mains voltage compatibility: 24 V DC, 120 V AC, or 230 V AC
• Electrical connection via terminal block
• Available versions include models with position indicators (visual), fitted bypass/pilot gas valves, or integrated pressure switches
