Solenoid Valve for Gas/Air, Class A, 500 mbar, IP65 Rated

The HONEYWELL KROMSCHRODER VAS1T20N/NQGL is a Class A solenoid valve intended for use in applications requiring automatic shut-off of gas and air. It operates in compliance with EN 161 standards; the valve is normally closed when not energized, and is rated for a maximum operating pressure of 500 mbar. The unit includes features such as a pilot lamp and flow adjustment; ingress protection rated at IP65. This model holds certification indicating suitability for integration into systems meeting SIL 3 and PL e requirements.

Key features:

• Size range: 1 to 9; DN (nominal diameter): 10 to 125
• Connection options: threaded or flanged
• Operation modes: quick opening/quick closing or slow opening/quick closing
• Mains voltage compatibility: 24 V DC, 120 V AC, or 230 V AC
• Electrical connection via terminal
• Available versions include models with position indicator/visual indicator, fitted bypass or pilot gas valve, and fitted pressure switches DG../VC
