Solenoid Valve for Gas/Air, Class A, 500 mbar, IP65 Rated

The HONEYWELL KROMSCHRODER VAS225/-R/NW is a Class A solenoid valve intended for use in applications requiring automatic shut-off of gas and air. It compliant with EN 161 standards and is normally closed (de-energized state). The unit rated for a maximum operating pressure of 500 mbar, includes adjustable flow settings, and is equipped with a pilot lamp to indicate operational status. This model holds EU certification as well as FM and CSA approvals, and it is certified for use in systems up to SIL 3 and PL e.

Key features include:

• Size range: 1 to 9; nominal diameter (DN): 10 to 125
• Connection options: threaded or flanged
• Opening/closing types: quick opening & closing or slow opening & quick closing
• Mains voltage compatibility: 24 V DC, 120 V AC, or 230 V AC
• Electrical connection via terminal block
• Protection rating: IP65
• Available versions with position indicator, visual indicator, fitted bypass/pilot gas valve, or integrated pressure switches
