Solenoid Valve for Gas/Air, Class A, 500 mbar, IP65 Rated

The HONEYWELL KROMSCHRODER VAS125/-R/LQ is a Class A solenoid valve intended for use in applications requiring automatic shut-off of gas and air, conforming to EN 161 standards. This valve remains closed when de-energized and includes a pilot lamp and adjustable flow settings. It is rated for maximum operating pressure up to 500 mbar, has an IP65 enclosure rating, and is certified according to applicable EU, FM, and CSA standards. The unit is suitable for installation in systems with requirements up to SIL 3 or PL e.

Key features include:

• Size range: 1 to 9; nominal diameter (DN): 10 to 125
• Connection options: threaded or flanged
• Operation types: available with quick opening/closing or slow opening/quick closing operation types
• Mains voltage compatibility: compatible with mains voltages of 24 V DC, 120 V AC, or 230 V AC
• Electrical connection via terminal block
• Optional accessories include position indicator, visual indicator, bypass/pilot gas valve fittings, or pressure switches DG../VC
