Solenoid Valve for Gas/Air, Class A, 500 mbar, IP65 Rated

The HONEYWELL KROMSCHRODER VAS2-/NQGL is a Class A solenoid valve intended for use in automatic shut-off applications for gas and air systems. This valve is compliant with EN 161 standards, is closed when not energized, and supports a maximum operating pressure of 500 mbar. It features flow adjustment capabilities, an integrated pilot lamp, and has an ingress protection rating of IP65. The unit holds EU certification as well as FM and CSA approvals, and holds certification meeting requirements up to SIL 3 and PL e.

Key features include:

• Size range: 1 to 9; nominal diameter (DN): 10 to 125
• Connection options: threaded or flanged
• Opening/closing types: quick opening & closing or slow opening & quick closing
• Mains voltage options: 24 V DC, 120 V AC, or 230 V AC
• Electrical connection via terminal block
• Available versions include models with position indicators (visual), fitted bypass/pilot gas valves, or integrated pressure switches
