Solenoid Valve for Gas/Air, Class A, 500 mbar, IP65 Rated

The HONEYWELL KROMSCHRODER VAS240F/LKSR is a Class A solenoid valve intended for use in automatic shut-off applications involving gas and air, conforming to EN 161 standards. This unit remains closed when de-energized and includes a pilot lamp and adjustable flow control. It is rated for operation up to 500 mbar, has an IP65 rating for ingress protection, and is certified according to EU, FM, and CSA standards. The valve is suitable for installation in systems with requirements up to SIL 3 or PL e.

Key features include:

• Size range: 1 to 9; DN (nominal diameter): 10 to 125
• Connection options: threaded or flanged
• Opening/closing configurations: available with various opening/closing options
• Mains voltage compatibility: compatible with mains voltages of 24 V DC, 120 V AC, or 230 V AC
• Electrical connection via terminal block
• Available in models featuring position indicator/visual indicator, fitted bypass/pilot gas valve, or fitted pressure switches DG../VC
