Solenoid Valve for Gas/Air, Class A, 500 mbar, IP65, VCS Series
Mfr # KS88206988
Zoro # G015425529
Specifications
Product Information
Description
The HONEYWELL KROMSCHRODER VCS665F05NNWL3B/PPPP/MP3 is a Class A solenoid valve intended for use in applications requiring automatic shut-off of gas and air. This unit operates in accordance with EN 161 standards, remaining closed when de-energized, and supports a maximum operating pressure of 500 mbar. It features an integrated pilot lamp for status indication; includes flow adjustment capability, offering operational flexibility. The valve carries EU certification as well as FM and CSA approvals, with compatibility with systems meeting requirements up to SIL 3 and PL e.
Key features include:
- Size range: 1 to 9; DN (nominal diameter): 10 to 125
- Connection options: threaded or flanged
- Operation types: quick opening/quick closing or slow opening/quick closing
- Mains voltage compatibility: 24 V DC, 120 V AC, or 230 V AC
- Electrical connection via terminal block
- IP65 rated enclosure for ingress protection
- Available versions include models with position indicator, visual indicator, fitted bypass/pilot gas valve, or fitted pressure switches
