Solenoid Valve for Gas/Air, Class A, IP65, FM/CSA Approved

The HONEYWELL KROMSCHRODER VAS115R/NW is a Class A solenoid valve intended for use in applications requiring automatic shut-off of gas and air. When not energized, the valve is in a closed position. It includes a pilot lamp, adjustable flow mechanism, and has an IP65 ingress protection rating. The unit is certified to applicable EU standards; approved by FM and CSA, with suitability for systems up to SIL 3 and PL e.

Key features include:

• Size range: 1 to 9
• Nominal diameter (DN): 10 to 125
• Connection options: threaded or flanged
• Opening/closing types: quick opening/quick closing or slow opening/quick closing
• Mains voltage options: 24 V DC, 120 V AC, or 230 V AC
• Electrical connection via terminal block
• Available versions with position indicator, visual indicator, fitted bypass/pilot gas valve, or fitted pressure switches
