Solenoid Valve for Gas/Air, EN 161, Class A, IP65, SIL 3/PL e Rated

The HONEYWELL KROMSCHRODER VAS1T-/15N/NQGL is a Class A solenoid valve conforming to EN 161 standards. This valve is intended for use in automatic shut-off applications involving gas and air, remains closed when not energized, and includes a pilot lamp and adjustable flow settings. It is rated for maximum operating pressure up to 500 mbar, has an IP65 enclosure rating, and holds certification meeting SIL 3 and PL e requirements. The unit is certified for use in systems up to SIL 3 and PL e.

Key features include:

• Size range: 1 to 9; DN (nominal diameter): 10 to 125
• Connection options: threaded or flanged
• Operation types: quick opening/quick closing or slow opening/quick closing
• Mains voltage options: 24 V DC, 120 V AC, or 230 V AC
• Electrical connection via terminal block
• Available with position indicator, visual indicator, fitted bypass/pilot gas valve, or fitted pressure switches DG../VC
