Solenoid Valve for Gas/Air, NC, 500 mbar, IP65, VAS Series

The HONEYWELL KROMSCHRODER VAS120R/LKGL is a Class A solenoid valve intended for use in applications requiring automatic shut-off of gas and air. It operates in accordance with EN 161 standards and is normally closed (NC) type; closes when not energized. This valve is rated for a maximum operating pressure of 500 mbar, features a pilot lamp, flow adjustment capability, and an IP65-rated enclosure. The unit is assessed according to SIL 3 and PL e standards, with approvals from FM and CSA.

Key features include:

• Size range: 1 to 9; nominal diameter (DN): 10 to 125
• Connection options: threaded or flanged
• Operation types: quick opening/quick closing or slow opening/quick closing
• Mains voltage options: 24 V DC, 120 V AC, or 230 V AC
• Electrical connection via terminal block
• Available versions include models with position indicators (visual), fitted bypass/pilot gas valves, or integrated pressure switches
