Solenoid Valve - Gas/Air, EN 161, IP65, 500 mbar Max

The HONEYWELL KROMSCHRODER VAS BEISPIEL 3 is a Class A solenoid valve intended for use in the automatic shut-off of gas and air systems. It conforms to EN 161 standards, remains closed when not energized, and supports a maximum operating pressure of 500 mbar. The unit features flow adjustment capabilities, an integrated pilot lamp, and has an ingress protection rating of IP65. This solenoid valve is suitable for installation in applications requiring compliance with SIL 3 and PL e standards, with approvals from FM and CSA.

Key features include:

• Size range: 1 to 9; nominal diameter (DN): 10 to 125
• Connection options: threaded or flanged
• Operation modes: quick opening/quick closing or slow opening/quick closing
• Mains voltage options: 24 V DC, 120 V AC, or 230 V AC
• Electrical connection via terminal block
• Available versions with position indicator (visual), fitted bypass/pilot gas valve, or fitted pressure switches DG../VC
