Transmitter Type
|
Pressure Transmitter
|
|
Wetted Materials - Transmitters
|
316 Stainless Steel, Alumina Ceramic, Epoxy, Glass, Silicon
|
|
Range Values - Transmitter
|
0 to 300
|
|
Range Units - Transmitter
|
psi
|
|
Accuracy - Transmitter
|
+/-0.25% FSS
|
|
Electrical Connections - Transmitter
|
Delphi Packard Metri-Pack 150 Connector
|
|
Process Connection Type - Transmitter
|
Female Schrader SAE J512
|
|
Output - Transmitter
|
10% to 90% Vs, Ratiometric 5VDC
|
|
Operating Temp. - Transmitter
|
-40 Degrees to 257 Degrees F
|
|
Wiring Entry - Transmitter
|
1/2 in FNPT
|
|
Electrical Connections
|
Delphi Packard Metri-Pack 150 Connector
|
|
Process Connection
|
Female Schrader 7/16-20 SAE J512
|
|
Safety Rating
|
IP65
|
|
Range
|
0 to 300 psi
|
|
Accuracy
|
+/-0.25% of FSS
|
|
Wetted Materials
|
319 Stainless Steel, Alumina Ceramic, Epoxy, Glass, Silicon
|
|
Output
|
Ratiometric 5V D,10% to 90%Vs
|
|
Operating Temp.
|
-40 Degrees F to 257 Degrees F
|
|
Item
|
Pressure Transmitter
|
|
Compatible With
|
Harsh Media
|
|
Features
|
Life: Minimum of 10 Million Cycles to Operating Pressure, Response Time: Less Than2 ms
|
|
Thermal Error
|
+/-2%
|
|
Minimum Operating Temperature
|
-40 Degrees F
|
|
Maximum Operating Temperature
|
257 Degrees F
|
|
Maximum Pressure
|
300 psi
|
|
Intrinsically Safe
|
No
|
|
Explosion/Fire Proof
|
No
|
|
Type of Pressure
|
Absolute
|
|
Burst Pressure
|
1,500 psi
|
|
Pressure Units
|
psi
|
|
Housing Material
|
Stainless Steel
|
|
Wiring Entry
|
1/2 in FNPT Conduit Connection
|
|
Standards
|
ISO 9001, RoHS
|
|
Series
|
PX2
|
|
Process Connection Type
|
SAE
|
|
Storage Temperature Range
|
-40 Degrees F to 257 Degrees F (-40 Degrees C to 125 Degrees C)
|
|
Overpressure
|
1,000 psi
|
|
For Use With Media Type
|
HVAC/R
|
|
Minimum Pressure
|
0 psi
|
|
Response Time
|
2 msec
|
|
IP Rating
|
IP65; IP67
|
