Safety Interlock Switch - GSS Series, Roller Plunger, 2NO/2NC, IP67 Rated

  • Mfr # GSAA22C
  • Zoro # G4179831
product price:
$
549.99
/ea
Sold in multiples of 50 for $27,499.50
Free Shipping & Returns

Key Features

Style
Top Roller Plunger
Series
GSS
Actuator Length
1.99 in
AC Contact Rating
10 A
DC Contact Rating
0.1 to 10 A @ 250 V
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
GSAA22C
Zoro #
G4179831
UPC #
-
Country of Origin
Mexico

Dimensions

Actuator Length
1.99 in
Height
3.23 in
Width
1.65 in
Depth
1.65 in
Conduit Size
1/2 in NPT
Overall Width
1.65 in
Overall Depth
1.65 in
Overall Height
3.23 in
Fits Chest Size
Environmentally Sealed, Red Switch Body

Details

Item
Safety Interlock Switch
Style
Top Roller Plunger
Series
GSS
AC Contact Rating
10 A
DC Contact Rating
0.1 to 10 A @ 250 V
Contact Form
2NO/2NC
Connection Type
1/2 in NPT Conduit
IP Rating
IP67
Operating Temp. Range
-13 Degrees to 185 Degrees F
Positive Travel
18.3 mm
Operating Force
2.1 in-lb Max
Differential Travel
9 mm
Standards
CE, CSA, SIL3, UL Listed
Body Material
Zinc
Movement
Lateral
Actuator Style
Plunger, Roller
Description/Special Features
Steel Roller 0.49 in dia x 0.18 in wide, EN50041 Body Type, Non Plug-In, Shock 50G per IEC 68-2-27, Vibration 10G per IEC 68-2-26, Expected Mechanical Life 15 Million Operations, FP, OP, OT, PT All to EN50041, Head and Cover Fixed with TORX(R) Socket Head Screws (Driver Supplied)
NEMA Rating
1, 12, 13, 4
Contact Material
Gold Plated
Pre-travel
15mm
Electrical Connection
1/2 in NPT Conduit
Features
Environmentally Sealed, Red Switch Body
Operating Temperature - Maximum
185 Degrees F
Hazardous Location Specification
Not Rated
NEMA Enclosure Rating
1, 12, 13, 4
Circuitry Action
Slow Action
Pretravel
15 mm
Includes Actuating Key
No Actuating Key Included
Operating Temperature - Minimum
-13 Degrees F

Description

Honeywell’s GSS Series Safety Interlock Switch is an electromechanical switch manufactured in accordance with EN50041 standards, featuring a red zinc body for clear identification in various applications. This model uses a top roller plunger actuator and includes both NO and NC contacts with slow action circuitry. The switch is equipped with gold-plated contacts, supports both AC and DC ratings, and is rated for a maximum of 15 million mechanical operations under specified conditions.

Key features:

  • Contact configuration: 2NO/2NC, gold-plated
  • Actuator style: Plunger with steel roller (0.49 in diameter x 0.18 in wide), actuator length 1.99 in
  • Body material: Zinc; overall dimensions: Height 3.23 in, Width/Depth 1.65 in
  • Electrical ratings: AC—10 A; DC—0.1 to 10 A @ 250 V
  • Conduit size & connection type: 1/2 in NPT conduit
  • Operating force: Max 2.1 in-lb; movement type: Lateral
  • Travel specifications: Pre-travel—15 mm; differential travel—9 mm; positive travel—18.3 mm
  • Temperature range: -13°F to +185°F
  • NEMA enclosure rating: Types 1, 4, 12, and 13; IP67 rated
  • Standards met: CE, CSA, SIL3, UL Listed
  • Additional features include non plug-in design with fixed head/cover secured by TORX® socket screws (driver supplied), tested for vibration resistance up to 10G as per IEC standard
