Shop HONEYWELL

Snap Action Switch, Lever, Roller Actuator, SPDT, 20 A at 480 V AC Contact Rating

  • Mfr # BA-2RV22-A2

  • Zoro # G0536812

product price:  $25.15
/ea

Key Features

Actuator Type - Snap Action Switch
Lever, Roller
AC Contact Rating - Snap Action Switch
20 A @ 480 V
DC Contact Rating - Snap Action Switch
20 A @ 230 V
Contact Form- Switches
SPDT
Lever Actuator Length - Snap Action Switch
1.05 in
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
BA-2RV22-A2
Zoro #
G0536812
UPC #
-
Country of Origin
Mexico

Dimensions

Lever Actuator Length - Snap Action Switch
1.05 in
Height - Snap Action Switch
0.95 in
Width - Snap Action Switch
1.94 in
Depth - Snap Action Switch
0.06 in
Height
0.95"
Mounting Dimension
1.00" Centers
Actuator Length
1.05"
Length
1.94"
Mounting Dimension - Snap Action Switch
1.00 in Centers
Depth
0.063"
Overall Height
0.95 in
Lever Actuator Length
1.05 in
Body Depth
0.06 in
Body Height
0.95 in
Mounting Hole Diameter
1/8 in
Overall Width
1.94 in
Body Width
1.94 in
Overall Depth
0.06 in

Details

Item
Snap Action Switch
Actuator Type - Snap Action Switch
Lever, Roller
AC Contact Rating - Snap Action Switch
20 A @ 480 V
DC Contact Rating - Snap Action Switch
20 A @ 230 V
Contact Form- Switches
SPDT
Watertight - Snap Action Switch
No
Voltage Rating
125/250/480VAC
Type of Actuator
Roller Lever
Current Rating
20A
Terminal Type
Screw
Release Force
1.5 ozf
Over Travel
0.03 in
Standards
CE, CSA, ENEC, UKCA, UL Listed
Housing Material
Phenolic
Operating Force
6 oz
Contact Form
1NO/1NC
Differential Travel
0.045 in
Series
BA
Electrical Connection - Snap Action Switch
Screw
Operating Temp. Range
-67 Degrees to 185 Degrees F
Max. Pretravel
0.25 in
DC Contact Rating
0.25 A @ 250 V, 0.5 A @ 125 V
AC Contact Rating
20 A @ 250 V
Over-Travel
0.094 in (2.39mm) OT
Operating Temperature
-67°F (-55°C) to 185°F (85°C)
Connection
Screw Terminal
Differential-Travel - max
0.045 in (1.14mm) DT
Operator Configuration
Standard
Type
Basic Limit Switch
Head Action
Spring Return, Standard
Force to Operate
6 oz (1.67N) OF
Contact Rating
20A 125-480Vac (10A125Vac Tungsten) 0.5A 125Vdc 0.25A 250Vdc
Connection Configuration
Bottom Facing Screw w/Cup Washer, 6-32 x 0.218 in.
Pre-Travel - max
0.25 in (6.35mm) PT
Operating Force - Minimum
1.67 N
Actuator Style
Roller Lever
Operating Temperature - Minimum
-67 Degrees F
Operating Temperature - Maximum
185 Degrees F
Pretravel
0.25 in
Electrical Connection
Screw Terminal
Operating Force - Maximum
6 ozf
Center Mounting Hole Distance
1 in
Body Material
Phenolic
Differential Travel - Maximum
0.045 in
Overtravel
0.03 in
Mounting Hole Horizontal Center to Center Distance
1 in

Description

Snap Action Switch, Lever, Roller, AC Contact Rating - Snap Action Switch 20 A @ 480 V, DC Contact Rating - Snap Action Switch 20 A @ 230 V, Contact Form- Switches SPDT, Lever Actuator Length - Snap Action Switch 1.05 in, Height - Snap Action Switch 0.95 in, Width - Snap Action Switch 1.94 in, Depth - Snap Action Switch 0.06 in, Electrical Connection - Snap Action Switch Screw, Mounting Dimension - Snap Action Switch 1.00 in Centers, Series BA
