Snapconnect receptacle

The HUBBELL Snapconnect receptacle is a duplex straight blade receptacle designed for modular wiring installations. It features SNAPConnect® technology, allowing the modular connector to be installed during rough-in and quickly snapped into place after wall installation. This hospital grade device provides two tamper resistant outlets and includes integrated USB charging ports—one Type A and one Type C—for added versatility in residential settings.

Key Features of the HUBBELL Snapconnect Receptacle:

• Contact Material: Copper contacts are used for electrical connections.


• Current Rating: Rated for 15 A at 125V AC with NEMA 5-15R configuration.


• USB Charging Capacity: Two USB ports (Type A & C); maximum output: 3A at 9V; rated for 10,000 cycles.


• Grade: Thermoplastic housing; hospital grade classification.


• Resistance Properties: Tamper resistant design intended to reduce the risk of foreign object insertion.


• Mounting: Flush mount type with included mounting screw and strap; center-to-center height is 3.81 in.


• Wire Compatibility: Accepts wire sizes from 14 AWG to 10 AWG using back-wiring method via modular connection; supports three wires (grounded).


• Operating Temperature Range: Operating temperature range: -40°F to 167°F maximum.


• Status Indicator: Equipped with power indicating light for operational status feedback.


• Standards Compliance: UL94 V-2 flammability rating; complies with cULus Listed to UL498, UL1310 standards
