  11. Flanged Locking Receptacle, L5-15R, 15 A, 125V AC, Single Phase, 2 Pole, Flush Mount, White
Hubbell Wiring Device-Kellems Flanged Locking Receptacle, L5-15R, 15 A, 125V AC, Single Phase, 2 Pole, Flush Mount, White HBL4715C - main

Flanged Locking Receptacle, L5-15R, 15 A, 125V AC, Single Phase, 2 Pole, Flush Mount, White

  • Mfr # HBL4715C

  • Zoro # G2356934

product price: $28.35
/ea

Key Features

NEMA Receptacle Configuration
L5-15R
Current Rating
15 A
Voltage Rating
125V AC
Phase
Single
Number of Poles
2
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
HBL4715C
Zoro #
G2356934
UPC #
783585171005
Country of Origin
United States

Dimensions

Maximum Wire Size
10 AWG
Minimum Wire Size
18 AWG
Wire Size
15A #14 AWG
Height
1.72 in
Dimensions
2.56 in x 2.56 in x 1.72 in
Length
2.56 in
Width
2.56 in

Details

Item
Flanged Locking Receptacle
NEMA Receptacle Configuration
L5-15R
Current Rating
15 A
Voltage Rating
125V AC
Phase
Single
Number of Poles
2
Number of Wires
3
Wire Connection Type
Screw Terminals
Shrouded
No
Grounding
Grounded
Housing Color
White
Mount Type
Flush
Cover Type
No Cover
IP Rating
IP20
NEMA Enclosure Rating
12, 4X
Standards
CSA Certified C22.2 No. 42, Federal Specification W-C-596, UL 498
Resistance Properties
Impact Resistant, Moisture Resistant
Flange Type
Flanged
Mounting Type
Flush Mount
Special Features
With Cover
Wiring Style
Standard
Grade
Industrial
Material
Thermoset
Number of Gangs
1
Horsepower Rating
1/2 hp
Features
Accepts Slotted, Phillips, and Robertson Head Drivers
Includes
Mounting Screws
AFCI
No
Includes Mounting Hardware
Yes
For Location
Indoor
Polarized
Yes
Maximum Operating Temperature
167 Degrees F
Minimum Operating Temperature
-40 Degrees F
Connection Orientation
Straight
Market
Industrial
Housing Material
Nylon
Flange Shape
Oval
For Environment
Dry
Contact Material
Brass
Spring Material
Brass
Flange Material
Natural White Nylon
Lock Type
Twist-lock
Flammability
HB or better per UL94/CSA 22.2 No.0.17
Terminal Designations
Terminals identified in accordance with UL 498
Application
Insulgrip
Material - Mounting Hardware
Screw Mounting
Dielectric Strength
Withstands 2,000V minimum
Performance
Electrical - Current Interrupting - Certified for current interrupting at full rated current Electrical - Dielectric Voltage - Withstands 2,000V minimum Environmental - Flammability - HB or better per UL94/CSA 22.2 No.0.17 Environmental - Moisture Resistance - IP20 Suitability Environmental - Operating Temperatures - Maximum Continuous 75°C, Minimum -40°C (w/o impact) Mechanical - Terminal Accommodation - #18 AWG - #10 AWG solid or stranded copper wire only. Mechanical - Terminal Identification - Terminals identified in accordance with UL 498
OEM Brand Name
Hubbell Wiring Device-Kellems
Amperage Rating
15 A
Amps
15

Description

The HUBBELL 15A Flanged Twist-Lock Receptacle is a flanged locking receptacle intended for use in industrial settings requiring locking electrical connections. This device features a twist-lock mechanism, rated for 15 amps and 125V AC, with a NEMA L5-15R configuration. Constructed from impact-resistant thermoplastic and nylon materials, it is suitable for indoor dry locations where reliable power connectivity is required.


Key Features of the HUBBELL 15A Flanged Twist-Lock Receptacle:

  • Amperage/Voltage: Rated for 15 A at 125V AC single phase

  • NEMA Configuration: L5-15R (2-pole, 3-wire)

  • Material Construction: Thermoplastic housing with nylon flange (impact resistance per manufacturer specifications)

  • Mounting Type: Flush mount design; includes mounting screws and hardware

  • Wire Termination: Backwired screw terminals accept #18 to #10 AWG copper wire; accepts slotted, Phillips, and Robertson drivers

  • Operating Temperature Range: -40°C to +75°C (without impact)

  • Dielectric Strength & Performance: Rated dielectric strength: minimum 2,000V; listed as current interrupting at full rated current per certification standards

  • Flammability Rating: HB or better per UL94/CSA standards

  • Covers & Protection: Includes cover; IP20 rating for indoor use only

  • Certifications & Standards: CSA C22.2 No.42, Federal Specification W-C-596, UL 498 listed
