  6. Kellems Wire Management, Cord Connectors, Straight Male, .13-.19", 1/4", Nylon
Hubbell Wiring Device-Kellems Kellems Wire Management, Cord Connectors, Straight Male, .13-.19", 1/4", Nylon SHC1002CR - main

Kellems Wire Management, Cord Connectors, Straight Male, .13-.19", 1/4", Nylon

  • Mfr # SHC1002CR

  • Zoro # G800618402

product price:  $10.45
/ea

Key Features

Style - Connector
Straight Male
Standards
UL 514B, CSA Certified
Knockout Size
0.54 to 0.57 in
Material
Nylon
Cable Opening Min.
0.13 in
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
SHC1002CR
Zoro #
G800618402
UPC #
783585207841
Country of Origin
United States

Dimensions

Knockout Size
0.54 to 0.57 in
Hub Size
1/4
Cord Dia. Range
0.13-0 .19 in (3.2- 4.7 mm)
Display Size
1/4 NPT

Details

Style - Connector
Straight Male
Standards
UL 514B, CSA Certified
Material
Nylon
Cable Opening Min.
0.13 in
Item
Cord Connectors
Color
Orange
Cable Opening Max.
0.19 in
Type
Straight Male
Temp. Rating
Minimum -30 Deg F to 225 Deg F (-34 Deg C to 107 Deg C)
Color Code
Red
Number Of Conductors
Single
Standard
UL Listed
Mounting Hardware Material
Locknut or Tapped Opening
Carton Quantity
50
Brand
Hubbell Wiring Device-Kellems
Nema Rating
NEMA Type 4, 4X, 12 and 13
Environmental Rating
Suitable For Use In Wet Locations When Used With A Listed Nylon Washer Between Box And Fitting.
Series
Standard Duty
Application
Straight Male- Form 1
Industry Standard(s)
UL Listed
Item Type
Cord Connectors
Performance
Environmental - Flammability - UL 94-V2 Environmental - Hazardous Locations - Used in hazardous locations per Class I Div. 2, Class II Div. 1 & 2, Class Ill Div. 1 & 2 in accordance with the NEC Environmental - Operating Temperatures - -30°F to +225°F (-34°C to +107°C)
OEM Brand Name
Hubbell Wiring Device-Kellems
Material - Mounting Hardware
Locknut or Tapped Opening
Environmental Conditions
Suitable For Use In Wet Locations When Used With A Listed Nylon Washer Between Box And Fitting.
Temperature Rating
Minimum -30 Deg F to 225 Deg F (-34 Deg C to 107 Deg C)
Conductor Range
0.13-0 .19 in (3.2- 4.7 mm)

Description

Hubbell Wiring Device Kellems, Kellems Wire Management, Cord Connectors,Straight Male, .13-.19", 1/4", Nylon
