  11. Liquid Tight Connector, 1in, Straight, Pink
Hubbell Wiring Device-Kellems Liquid Tight Connector, 1in, Straight, Pink SHC1044CR - main

Liquid Tight Connector, 1in, Straight, Pink

  • Mfr # SHC1044CR

  • Zoro # G2424371

product price: $12.49
/ea

Key Features

Material
Nylon
Box Connection
1 in MNPT
Standards
CSA LR27378, UL E54218(M)
Cord Dia. Range
1.00 in to 1.13 in
Connector Type
Straight
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
SHC1044CR
Zoro #
G2424371
UPC #
783585208169
Country of Origin
United States

Dimensions

Cord Dia. Range
1.00 in to 1.13 in
Length
2-35/64"
Length - Box to End of Connector
1 3/4 in
Conduit Size
1"
Length - External Strain Relief
No External Strain Relief
Hub Size
1 in MNPT
Overall Length
2 1/2 in
Compatible Conduit Trade Size
1 in
Thread Size
1 in
Form Size
F4
Dimension D
1.01" (25.7) Throat Dia.
Dimension B
1.75" (44.4) Ref.
Dimension E A/C
1.84" (46.7)
Dimension A
1.88" (47.8) Dia.
Dimension E A/F
1.63" (41.4)
Dimension C
.70" (17.8)
Cord Diameter Range
1.00"- 1.13" (25.4- 28.6)
Recommended Knockout Hole Size
1.36"- 1.41" (34.5-35.7)
Display Size
1" NPT

Details

Item
Liquid Tight Cord Connector
Material
Nylon
Box Connection
1 in MNPT
Standards
CSA LR27378, UL E54218(M)
Connector Type
Straight
Color
Pink
Item - Cord Connector
Liquid Tight Cord Connector
Material - Cord Connector
Nylon
Body Color - Cord Connector
Gray
Gland Color Code
Pink
Material - External Strain Relief
No External Strain Relief
Hazardous Location Rating
Class I, Division 2, Class II, Division 1 & 2, Class III, Division 1 & 2
Strain Relief Type
No External Strain Relief
Insulated
Yes
Number of Cords
1
Style - Connector
Straight
For Use With
Kellems Wire Management
Maximum Operating Temperature
225 Degrees F
Liquid Tight
Yes
NEMA Rating
NEMA 12, NEMA 13, NEMA 4, NEMA 4X
Environmental Rating
Not Flammable, Hazardous Locations
Minimum Operating Temperature
-30 Degrees F
Bushing Material
Neoprene
Body Color
Gray
Collar Material
Nylon
Thread Gender
Male
Compatible Conduit Type
Liquid Tight Cord Connector
Thread Type
NPT Thread
IP Rating
IP66
For Maximum Cable OD
1.13 in
Resistance Properties
Corrosion Resistant
For Minimum Cable OD
1 in
Connection Orientation
Straight
Grommet Color Code
Pink
Body Material
Nylon
Hazardous Locations
Hubbell cord connectors are suitable for use in hazardous locations per Class I Div. 2, Class II Div. 1 & 2, Class III Div. 1 & 2 N.E.C. Reference 501-4(b), 502-4(a), 502-4(b), 503-3(a), and 503-3(b).
Color Code
Pink
Cord Connector Body Style
Straight Male
Material/Style
Nylon Standard Style
Flammability
Hubbell nylon cord connectors have a UL 94-V2 rating.
Product Type
Cord Connectors
Effective Operating Temperature
-30°F to +225°F (-34°C to +107°C)
Certifications
UL Listed in accordance with Standard 514B, CSA Certified, United States Coast Guard Approval, Title 46-Part 111.
Conductor Range
1-1.13 in (25.4- 28.6 mm)
Temperature Rating
Minimum -30 Deg F to 225 Deg F (-34 Deg C to 107 Deg C)
Number Of Conductors
Single
Type
Straight Male
Series
Standard Duty
Environmental Conditions
Suitable For Use In Wet Locations When Used With A Listed Nylon Washer Between Box And Fitting.
Item Type
Cord Connectors
Material - Mounting Hardware
Locknut or Tapped Opening
Application
Straight Male- Form 4
OEM Brand Name
Hubbell Wiring Device-Kellems
Performance
Environmental - Flammability - UL 94-V2 Environmental - Hazardous Locations - Used in hazardous locations per Class I Div. 2, Class II Div. 1 & 2, Class Ill Div. 1 & 2 in accordance with the NEC Environmental - Operating Temperatures - -30°F to +225°F (-34°C to +107°C)
Industry Standard(s)
UL Listed

Description

Liquid Tight Cord Connector, Cord Dia. Range 1.00 in to 1.13 in, Box Connection 1 in MNPT, Material - Cord Connector Nylon, External Strain Relief Material No External Strain Relief, Gland Color Code Pink, Body Color - Cord Connector Gray, Number of Cords 1, Style - Connector Straight, Strain Relief Type No External Strain Relief, External Strain Relief Length No External Strain Relief, Length - Box to End of Connector 1 3/4 in, Insulated Yes, Standards CSA LR27378, UL E54218(M)
