  11. Locking Plug, Non-NEMA, 30 A, 480V AC, Three Phase, 3 Pole, Screw Terminals, Black, White
Hubbell Wiring Device-Kellems Locking Plug, Non-NEMA, 30 A, 480V AC, Three Phase, 3 Pole, Screw Terminals, Black, White HBL20445B - main

Locking Plug, Non-NEMA, 30 A, 480V AC, Three Phase, 3 Pole, Screw Terminals, Black, White

  • Mfr # HBL20445B

  • Zoro # G2067116

product price: $198.99
/ea
Free Shipping & Returns

Key Features

NEMA Plug Configuration
Non-NEMA
Voltage Rating
480V AC
Phase
Three
Number of Poles
3
Number of Wires
4
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
HBL20445B
Zoro #
G2067116
UPC #
783585017266
Country of Origin
United States

Dimensions

For Maximum Cable Diameter
1.20 in
For Minimum Cable Diameter
0.70 in
Cord Size
0.630 in to 1.200 in
Body Length
2.33 in
Maximum Wire Size
6 AWG
Outside Diameter
2.53 in
Minimum Wire Size
10 AWG
Wire Size
#10 AWG to #6 AWG
Length
2.33 in
Dimensions
2.33 in x 0.94 in x 5.63 in
Height
5.63 in
Width
0.94 in

Details

Item
Locking Plug
NEMA Plug Configuration
Non-NEMA
Current Rating
30 A
Voltage Rating
480V AC
Phase
Three
Number of Poles
3
Number of Wires
4
Number of Blades
4
Wire Connection Type
Screw Terminals
Wiring Style
Standard
Connection Orientation
Straight
Shrouded
No
Grounding
Grounded
Housing Color
Black, White
IP Rating
IP20
Standards
CSA Certified, UL Listed
Resistance Properties
Chemical Resistant, Impact Resistant
Grade
Industrial
Material
Nylon
Minimum Operating Temperature
-40 Degrees C
Polarized
Yes
Maximum Operating Temperature
75 Degrees C
Market
Industrial
Housing Material
Nylon
Blade Material
Brass
Flammability
HB or better per UL 94 or CSA 22.2 No. 0.6
Dielectric Strength
Withstands 2,000V minimum
Cord Range
0.700"-1.200" (17.78-30.5)
Performance
Electrical - Current Interrupting - Certified for current interrupting at full rated current Electrical - Dielectric Voltage Withstand - 2,000V minimum Environmental - Flammability - UL 94 VO for Receptacles and Inlets. HB or better for Plugs and Connectors Environmental - Moisture Resistance - IP30 Suitability Environmental - Operating Temperatures - Maximum Continuous 75°C,Minimum -40°C (w/o impact) Mechanical - Terminal Accommodation - #10 AWG - #6 AWG stranded copper wire only. Mechanical - Terminal Identification - Terminals identified in accordance with UL 498
Amperage Rating
30 A
Amps
30
Antimicrobial
No
NEMA Configuration
Non-NEMA, 4 Blade

Description

The HUBBELL 30A Locking Plug 3P 4W 480VAC RD is an industrial-grade locking plug intended for use in industrial environments requiring locking plug configurations. It features a nylon housing for impact resistance and uses screw terminals compatible with #10 AWG to #6 AWG stranded copper wire. Molded-in brass male contacts are integrated into the nose.


Key Features of the HUBBELL - 30A Locking Plug:

  • Amperage/Voltage Rating: Rated for 30 A at 480V AC

  • Configuration: Non-NEMA, four blades; three poles, four wires; grounded

  • Cable Range: Accepts cables from 0.700" to 1.200" diameter

  • Wire Size Compatibility: Supports #10 AWG to #6 AWG stranded copper wire

  • Nylon body construction

  • Connection Type: Screw terminals with pressure pads enhance termination strength

  • Molded-In Contacts: Brass male contacts are integrated into the nose

  • Strain Relief: Three-piece clamp assembly designed to help limit strain, moisture, and dust entry at connection point

  • Operating Temperature Range: Suitable for continuous use from -40°C to +75°C (without impact)

  • Flammability Rating & Standards Compliance: UL94 V-0 flammability rating; CSA Certified; UL Listed
