  11. Straight Blade Plug, 10-20P, 20 A, 125/250V AC, 3 Pole, Screw Terminals, Non-Grounded
Hubbell Wiring Device-Kellems Straight Blade Plug, 10-20P, 20 A, 125/250V AC, 3 Pole, Screw Terminals, Non-Grounded HBL9977C - main

Straight Blade Plug, 10-20P, 20 A, 125/250V AC, 3 Pole, Screw Terminals, Non-Grounded

  • Mfr # HBL9977C

  • Zoro # G0545833

product price: $34.49
/ea

Key Features

NEMA Plug Configuration
10-20P
Current Rating
20 A
Voltage Rating
125/250V AC
Phase
Single
Number of Poles
3
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
HBL9977C
Zoro #
G0545833
UPC #
783585013121
Country of Origin
United States

Dimensions

For Maximum Cable Diameter
0.78 in
For Minimum Cable Diameter
0.385 in
Cord Size
0.385 in to 0.780 in
Outside Diameter
1.94 in
Body Length
2.5 in

Details

Item
Straight Blade Plug
NEMA Plug Configuration
10-20P
Current Rating
20 A
Voltage Rating
125/250V AC
Phase
Single
Number of Poles
3
Number of Blades
3
Wire Connection Type
Screw Terminals
Wiring Style
Standard
Connection Orientation
Straight
Grounding
Non-Grounded
Housing Color
Black
IP Rating
IP20
Standards
CSA, UL
Resistance Properties
Corrosion Resistant
Corrosion Resistant
Yes
Grade
Industrial
Boot Code
A
Grade - Plugs and Receptacles
Industrial
HP
1.0 Line to Neutral, 2.0 Line to Line
NEMA Plug Configuration - Plugs and Receptacles
10-20P
Number of Wires
3
Voltage
125/250VAC
Special Features
Corrosion resistant
Antimicrobial
No
Material
Nylon
Phase - Plugs and Receptacles
3
Polarized
Yes
Insulation Material
Nylon
Market
Industrial
Horsepower Rating
1 hp, 2 hp
Housing Material
Nylon
Contact Blades Material
.075 Brass
Retainer Material
Polycarbonate
Terminal Screw Material
Brass - Nat. or Ni Plated
Flammability
UL 94 HB or better.
Weight (Lbs.)
0.3
Dielectric Strength
Withstands 2,000V minimum
Cord Clamp Material
Nylon
Temp. Rise
Max 30°C temperature rise at full rated current after 50 cycles of overload at 150% of rated current at a power factor of 75%..
Body Style
Straight
Operating Temp.
Maximum continuous 75°C; minimum 40°C (w/o impact); Maximum continuous 75°C, minimum -40°C (w/o impact).
Blade Holder Material
Nylon

Description

Straight Blade Plug, Connection Orientation Straight, Current Rating 20 A, Grounding Non-Grounded, Horsepower Rating 1 hp, 2 hp, Housing Color Black, IP Rating IP20, NEMA Plug Configuration 10-20P, Number of Blades 3, Number of Poles 3, Phase Single, Polarized Yes, Resistance Properties Corrosion Resistant, Voltage Rating 125/250V AC, Wire Connection Type Screw Terminals, Wiring Style Standard, For Maximum Cable Diameter 0.78 in, For Minimum Cable Diameter 0.385 in, Grade Industrial
