  11. Straight Blade Plug, 15-20P, 20 A, 250V AC, 3 Pole, Screw Terminals, Grounded
Hubbell Wiring Device-Kellems Straight Blade Plug, 15-20P, 20 A, 250V AC, 3 Pole, Screw Terminals, Grounded HBL8421C - main

Straight Blade Plug, 15-20P, 20 A, 250V AC, 3 Pole, Screw Terminals, Grounded

  • Mfr # HBL8421C

  • Zoro # G3103563

product price: $71.35
/ea

Key Features

NEMA Plug Configuration
15-20P
Current Rating
20 A
Phase
Three
Number of Poles
3
Number of Blades
4
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
HBL8421C
Zoro #
G3103563
UPC #
783585013299
Country of Origin
United States

Dimensions

For Maximum Cable Diameter
0.775 in
For Minimum Cable Diameter
0.39 in
Cord Size
0.390 in to 0.775 in

Details

Item
Straight Blade Plug
NEMA Plug Configuration
15-20P
Current Rating
20 A
Voltage Rating
250V AC
Phase
Three
Number of Poles
3
Number of Blades
4
Wire Connection Type
Screw Terminals
Wiring Style
Standard
Connection Orientation
Angled
Grounding
Grounded
Housing Color
Black, White
IP Rating
IP20
Standards
CSA, UL
Resistance Properties
Corrosion Resistant
Grade
Industrial
Phase - Plugs and Receptacles
3
Voltage
250VAC
NEMA Plug Configuration - Plugs and Receptacles
15-20P
Corrosion Resistant
Yes
Special Features
Corrosion resistant
Antimicrobial
No
NEMA Configuration
15-20
Number of Wires
4
Grade - Plugs and Receptacles
Industrial
Material
Nylon
HP
3.0
NEMA Rating
15-20P
Insulation Material
Nylon
Horsepower Rating
3 hp
Housing Material
Nylon
Polarized
Yes
Market
Industrial
Cord Clamp Material
Nylon
Retainer Material
Polycarbonate
Flammability
UL 94 HB or better.
Temp. Rise
Max 30°C temperature rise at full rated current after 50 cycles of overload at 150% of rated current at a power factor of 75%..
Terminal Screw Material
Brass
Ground Screw Material
Plated Steel
Ground Contact Blade Material
.075" Brass
Contact Blades Material
.075" Brass
Blade Holder Material
Nylon
Body Style
Angle
Operating Temp.
Maximum continuous 75°C; minimum -40°C (w/o impact)
Dielectric Strength
Withstands 2,000V minimum
Weight (Lbs.)
0.35

Description

Angle Straight Blade Plug, Connection Orientation Angled, Current Rating 20 A, Grounding Grounded, Horsepower Rating 3 hp, Housing Color Black, White, IP Rating IP20, NEMA Plug Configuration 15-20P, Number of Blades 4, Number of Poles 3, Phase Three, Polarized Yes, Resistance Properties Corrosion Resistant, Voltage Rating 250V AC, Wire Connection Type Screw Terminals, Wiring Style Standard, For Maximum Cable Diameter 0.775 in, For Minimum Cable Diameter 0.39 in, Grade Industrial
