  6. Straight Blade Plug, 15-50P, 50 A, 250V AC, 3 Pole, Screw Terminals, Grounded
Hubbell Wiring Device-Kellems Straight Blade Plug, 15-50P, 50 A, 250V AC, 3 Pole, Screw Terminals, Grounded HBL8451C - main

Straight Blade Plug, 15-50P, 50 A, 250V AC, 3 Pole, Screw Terminals, Grounded

  • Mfr # HBL8451C

  • Zoro # G0268877

product price:  $103.99
/ea
Free Shipping & Returns

Key Features

NEMA Plug Configuration
15-50P
Phase
Three
Number of Poles
3
Number of Blades
4
Wire Connection Type
Screw Terminals
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Unlock tax-exempt savings
Add Tax Exemption

Specifications

Product Information

MFR #
HBL8451C
Zoro #
G0268877
UPC #
783585015163
Country of Origin
United States

Dimensions

For Maximum Cable Diameter
1.31 in
For Minimum Cable Diameter
0.625 in
Cord Size
0.625 in to 1.310 in
Minimum Wire Size
12 AWG
Maximum Wire Size
4 AWG
Wire Size
#12 AWG to #4 AWG

Details

Item
Straight Blade Plug
NEMA Plug Configuration
15-50P
Current Rating
50 A
Voltage Rating
250V AC
Phase
Three
Number of Poles
3
Number of Blades
4
Wire Connection Type
Screw Terminals
Wiring Style
Standard
Connection Orientation
Straight
Grounding
Grounded
Housing Color
Black
IP Rating
IP20
Standards
CSA, UL
Resistance Properties
Corrosion Resistant
HP
7.5
NEMA Plug Configuration - Plugs and Receptacles
15-50P
Grade
Industrial
Grade - Plugs and Receptacles
Industrial
Material
Nylon
Corrosion Resistant
Yes
Antimicrobial
No
Phase - Plugs and Receptacles
3
Boot Code
C
Voltage
250VAC
Special Features
Corrosion resistant
Number of Wires
4
Minimum Operating Temperature
-40 Degrees F
Market
Industrial
Housing Material
Nylon
Maximum Operating Temperature
167 Degrees F
Polarized
Yes
Insulation Material
Nylon
Horsepower Rating
7 1/2 hp
Flammability
UL 94 HB or better.
Box Terminals Material
Copper
Body Style
Straight
Operating Temp.
Maximum continuous 75°C, minimum -40°C (w/o impact).
Cord Clamp Material
Glass Reinforced Polyester
Temp. Rise
Max 30°C temperature rise at full rated current after 50 cycles of overload at 150% of rated current at a power factor of 75%..
Weight (Lbs.)
0.85
Blade Holder Material
Glass Reinforced PET
Retainer Material
Glass Reinforced PET
Terminal Screw Material
Steel - Zn plated
Ground Contact Blade Material
.075" Brass
Contact Blades Material
.100" Brass
Dielectric Strength
Withstands 2,000V minimum.
Ground Screw Material
3/8" Allen Head, Plated Steel
OEM Brand Name
Hubbell Wiring Device-Kellems
Operating Temperature
Maximum continuous 75°C and minimum -40°C without Impact

Description

Straight Blade Plug, Connection Orientation Straight, Current Rating 50 A, Grounding Grounded, Horsepower Rating 7 1/2 hp, Housing Color Black, IP Rating IP20, NEMA Plug Configuration 15-50P, Number of Blades 4, Number of Poles 3, Phase Three, Polarized Yes, Resistance Properties Corrosion Resistant, Voltage Rating 250V AC, Wire Connection Type Screw Terminals, Wiring Style Standard, For Maximum Cable Diameter 1.31 in, For Minimum Cable Diameter 0.625 in, Grade Industrial, Housing Material Nylon
